Main features
- One-way control: 8 doors
- Two-way control: 4 doors with Wiegand only, 8 doors with Wiegand, RS-485 and network connection
- 8 Wiegand 26-64 bit card readers
- 16 GV-Reader and GV-GF fingerprint readers via RS-485 and network
- Built-in 16 digital inputs and 24 relay outputs
- Suitable for controlling doors, parking barriers, as well as access control to the elevator call buttons.
- Hacking alarm function support
Specification
|
System requirments |
|
|
GV-ASManager version |
GV-ASManager V4.2.3 or higher |
|
Software |
|
|
One-way control |
8 doors |
|
Two-way control |
4 doors only with Wiegand, 8 doors with Wiegand, RS-485 and network connection |
|
Equipment |
|
|
CPU |
32-bit ARM7TDMI |
|
User cards number |
40 000 cards |
|
Event buffer |
1 000 000 events and journal entries |
|
Power |
100-250 V AC, 50-60 Hz |
|
Interface RS-485 |
2 interface RS-485 for GV-Reader and fingerprint readers GV-GF (up to 16 devices) |
|
Interface Wiegand |
8 interface Wiegand, 26-64 bit format |
|
Power source 12 V DC, 200 mA |
|
|
Interface TCP/IP |
1 interface TCP-IP for IP-readers GeoVision |
|
Сommunication |
TCP/IP |
|
Battery |
Interchangeable disk elementc |
|
Input |
16 in, dry contact, НР / НЗ |
|
Output |
24 relay out (30 В DC, 3 А; 110-250 В AC, 3 А) |
|
Operation temperature |
0-65 °C |
|
Operation humidity |
10% to 90% ОВ (without condensation) |
|
Dimensions (W x H x D) |
420 x 300 x 110 мм |
|
Weight |
4,4 kg |
|
Certification |
CE, FCC, RoHS |
